16' Storage Unit
16' Storage Unit
Our largest storage solution for demanding industrial applications. Ideal for property management companies and industrial operations with significant storage needs.
Maximum Storage for Industrial Needs
The 16′ Storage Unit is our largest offering, designed for industrial operations that demand maximum storage capacity. With over 1,000 cubic feet of space, it’s the go-to solution for warehouses, manufacturing facilities, and large property portfolios.
Built with upgraded 12-gauge industrial steel, this unit is engineered to withstand the most demanding environments. The reinforced floor supports heavy equipment, pallet jacks, and even small forklifts.
Optional climate control packages make this unit suitable for temperature-sensitive inventory, while multiple door configurations provide flexible access options for your specific workflow.
Key Benefits
- Over 1,000 cu ft of storage space
- Industrial-grade 12-gauge steel
- Climate control options available
- Multiple door configurations
Standard Features
Maximum Capacity
Over 1,000 cubic feet of storage space for large-scale operations.
Industrial-Grade Steel
12-gauge corrugated steel walls for maximum durability and security.
Multiple Access Points
Optional side door and personnel door configurations available.
Climate Options
Available with insulation and HVAC prep for climate-sensitive storage.
Heavy-Duty Stacking
Reinforced corner castings support stacking up to 4 units high.
Transport Ready
Standard ISO dimensions for easy transport on flatbed trucks.
What's Included
- Wall panels
- Roof panel
- Reinforced floor
- Double doors
- Hardware kit
- Security lock box
- Tie-down rings
- Ventilation system
Technical Specifications
Dimensions & Details
| External Length | 16′ 0″ (4.88m) |
| External Width | 8′ 0″ (2.44m) |
| External Height | 8′ 6″ (2.59m) |
| Internal Length | 15′ 8″ (4.78m) |
| Internal Width | 7′ 8″ (2.34m) |
| Internal Height | 8′ 0″ (2.44m) |
| Door Opening Width | 7′ 6″ (2.29m) |
| Door Opening Height | 7′ 6″ (2.29m) |
| Cubic Capacity | 1,088 cu ft (30.8 m³) |
| Tare Weight | 3,000 lbs (1,361 kg) |
| Max Payload | 14,000 lbs (6,350 kg) |
| Floor Load Capacity | 400 lbs/sq ft |
Construction Details
| Wall Material | 12-gauge steel |
| Floor Material | 28mm marine plywood |
| Finish | Industrial powder coat |
| Color Options | Gray, Beige, Green, Blue, Custom |
