16' Storage Unit
16' Storage Unit
Our largest storage solution for demanding industrial applications. Ideal for property management companies and industrial operations with significant storage needs.
Maximum Storage for Industrial Needs
The 16′ Storage Unit is our largest offering, designed for industrial operations that demand maximum storage capacity. With over 1,000 cubic feet of space, it’s the go-to solution for warehouses, manufacturing facilities, and large property portfolios.
Built with upgraded 20-gauge industrial steel, this unit is engineered to withstand the most demanding environments. The reinforced floor supports heavy equipment, pallet jacks, and even small forklifts.
Key Benefits
- Over 1,000 cu ft of storage space
- Industrial-grade 20-gauge steel
- Multiple door configurations
Standard Features
Maximum Capacity
Over 1,000 cubic feet of storage space for large-scale operations.
Industrial-Grade Steel
20-gauge corrugated steel walls for maximum durability and security.
Transport Ready
Standard ISO dimensions for easy transport on flatbed trucks.
What's Included
- Wall panels
- Roof panel
- Reinforced floor
- Double doors
- Hardware kit
- Security lock box
- Tie-down rings
*Unassembled - Assembly available in select areas
Additional accessories available for purchase
Technical Specifications
Dimensions & Details
| External Length | 16′ 0″ |
| External Width | 8′ 0″ |
| External Height | 8′ 6″ |
| Internal Length | 15′ 8″ |
| Internal Width | 7′ 8″ |
| Internal Height | 8′ 0″ |
| Door Opening Width | 7′ 6″ |
| Door Opening Height | 7′ 6″ |
| Cubic Capacity | 1,088 cu ft |
| Tare Weight | 3,000 lbs |
| Max Payload | 14,000 lbs |
| Floor Load Capacity | 400 lbs/sq ft |
Construction Details
| Wall Material | 20-gauge steel |
| Floor Material | 28mm marine grade plywood |
| Finish | Industrial powder coat |
| Color Options | Light Gray, Dark Grey, Cream |
